eye3D Blue Specification

Camera
– CMOS IDS

Projectors
– 2

Measurement Points
– 350,000

Capture technique
– Profilometry and use of Fluorescein.

Repeatability
– Corneal 3μ
– Scleral 10μ
– Refractive 0.1D

PC requirements
– Windows 7 or higher
– At least 4GB of RAM
– One available USB 2.0 port

Energy and Power
– Plug power supply:
10W, PEU, 7.5V
– Power Supply Output Type: Fixed
– Input Voltage AC Min: 90V
– Input Voltage AC Max: 264V
– Output Voltage Nom.: 7.5V
– Output Current Max: 1.14A
– Output Power Max: 8W
– Output Connector: Barrel Plug
– SVHC: No SVHC (16-Jun-2014)
– Applications: General Purpose
– No. of Outputs: 1
– Output Current: 1.14A
– Output Voltage: 7.5V
– Power Rating: 8W

Dimensions
– Max Length (ground plate): 17 3/8” (44cm);
– Max Width (hand holds): 15 3/4” (40 cm);
– Max Height (chin rest): 23” (58.5 cm);
– Weight: 45 lbs (20 kg);
